Name: Danfoss Type 034l0049 Crankcase Pressure Regulator KVL 15
Brand: Ningbo Brando Hardware Co., Ltd
SKU: KVL 15
Price: 65.00 USD
Availability: InStock

होम उत्पाद प्रशीतन सोलोनाइड वाल्व

Danfoss Type 034l0049 Crankcase Pressure Regulator KVL 15

उत्पाद विवरण:

उत्पत्ति के प्लेस:	चीन
ब्रांड नाम:	BRANDO
प्रमाणन:	None
मॉडल संख्या:	KVL 15

भुगतान & नौवहन नियमों:

न्यूनतम आदेश मात्रा:	5पीसी
मूल्य:	बातचीत योग्य
पैकेजिंग विवरण:	भीतरी बॉक्स, कार्टन, फूस
प्रसव के समय:	बातचीत
भुगतान शर्तें:	टी/टी, वेस्टर्न यूनियन, मनीग्राम
आपूर्ति की क्षमता:	प्रति माह 100000 पीसीएस

संपर्क करें

विस्तृत उत्पाद विवरण

प्रोडक्ट का नाम:	क्रैंककेस दबाव नियामक	पोर्ट आकार:	5/8''
संबंध:	सोल्डर (ओडीएफ)	विनियमन सीमा:	0 से 6 बार, फ़ैक्टरी सेटिंग = 2 बार
अधिकतम कार्य दबाव:	14 बार	मध्यम तापमान सीमा:	-200 से +150 ℃
शीतल:	सीएफसी, एचसीएफसी, एचएफसी	मैक्स पी-बैंड:	2.0 बार
प्रमुखता देना:	Crankcase pressure regulator KVL 15 , Danfoss KVL 15 , Danfoss 034L0049 KVL 15

Danfoss Type 034l0049 Crankcase Pressure Regulator KVL 15

A CPR or crankcase pressure regulator is nothing more than a pressure reducing valve. When installed on a compressor suction inlet and properly adjusted, the CPR will prevent the compressor suction pressure from ever rising above the CPR's setting. The CPR will help prevent refrigeration compressor from overloading during startup on refrigeration systems that may experience heavy load conditions such as a freezer after a defrost cycle.

Product video of KVL 12 Crankcase Pressure Regulator:

Technical Data of KVL Crankcase Pressure Regulator:

Refrigerants	CFC, HCFC, HFC
Regulation Range	0 to 6 bar, Factory Setting = 2 bar
Max Working Pressure	14 bar
Max Test Pressure	KVL 12-22: 28 bar KVL 28-35: 25.6 bar
Medium Temperature Range	-200 to +150℃
Max P-band	KVL 12-22: 2.0 bar KVL 28-35: 1.5 bar

Ordering Code of KVL Crankcase Pressure Regulator:

Model	Rated Capacity (kW)				Flare	Code no	Solder	Code no
Model	R22	R134a	R404A/R507	R407C	Flare	Code no	Solder	Code no
KVL 12	7.1	5.3	6.3	6.5	1/2''	034L0041	1/2''	034L0043
KVL 15	7.1	5.3	6.3	6.5	5/8''	034L0042	5/8''	034L0049
KVL 22	7.1	5.3	6.3	6.5			7/8''	034L0045
KVL 28	17.8	13.2	15.9	16.4			1 1/8''	034L0046
KVL 35	17.8	13.2	15.9	16.4			1 3/8''	034L0052

Dimension of KVL Crankcase Pressure Regulator:

Model	Connection		H1	H2	B1	C Solder	φ D
Model	Flare	Solder	H1	H2	B1	C Solder	φ D
KVL 12	1/2''	1/2''	7.047''	3.898''	2.520''	0.375''	1.181''
KVL 15	5/8''	5/8''	7.047''	3.898''	2.520''	0.5''	1.181''
KVL 22		7/8''	7.047''	3.898''	2.520''	0.625''	1.181''
KVL 28		1 1/8''	10.197''	5.945''	4.134''	0.875''	1.693''
KVL 35		1 3/8''	10.197''	5.945''	4.134''	1''	1.693''

More Refrigeration Parts for you to choose:


Refrigeration Solenoid Valve	Reversing Valve	Refrigeration Ball Valve

Hot Gas Bypass Valve	Expansion Valve	Sight Glass

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
