Name: CMV-14S Mueller Type Refrigeration Magnetic Check Valve 7/8'' Solder
Brand: Ningbo Brando Hardware Co., Ltd
SKU: सीएमवी-14एस
Price: 65.00 USD
Availability: InStock

होम उत्पाद प्रशीतन सोलोनाइड वाल्व

CMV-14S Mueller Type Refrigeration Magnetic Check Valve 7/8'' Solder

उत्पाद विवरण:

उत्पत्ति के प्लेस:	चीन
ब्रांड नाम:	BRANDO
प्रमाणन:	None
मॉडल संख्या:	सीएमवी-14एस

भुगतान & नौवहन नियमों:

न्यूनतम आदेश मात्रा:	5पीसी
मूल्य:	बातचीत योग्य
पैकेजिंग विवरण:	भीतरी बॉक्स, कार्टन, फूस
प्रसव के समय:	बातचीत
भुगतान शर्तें:	टी/टी, वेस्टर्न यूनियन, मनीग्राम
आपूर्ति की क्षमता:	प्रति माह 100000 पीसी

संपर्क करें

विस्तृत उत्पाद विवरण

प्रोडक्ट का नाम:	प्रशीतन जाँच वाल्व	पोर्ट आकार:	7/8''
रिश्ते का प्रकार:	मिलाप	अनुकूलता:	सीएफसी, एचसीएफसी, एचएफसी और एचएफओ रेफ्रिजरेंट और तेल
अधिकतम कार्य दबाव:	55 बार 5/8'' आकार तक	कार्य तापमान:	-40 डिग्री सेल्सियस से 149 डिग्री सेल्सियस
प्रमुखता देना:	Mueller Magnetic Check Valve cmv-14s , Refrigeration Magnetic Check Valve 7/8'' , Mueller Refrigeration Check Valve 7/8''

CMV-14S Mueller Type Refrigeration Magnetic Check Valve 7/8'' Solder

Magnetic type refrigeration check valve is designed for installation in commercial refrigerating systems and in residential or industrial air conditioning plants. They are used to control the unidirectional flow of refrigerant to prevent backflow; the magnetic actuator guarantees a high reliability standard. When you install the refrigeration check valve in the system, it will rapidly balance the high pressure and low pressure inside of the compressor when the compressor stops working, when it reaches balance, then the refrigerants won't flow until the air conditioning or the refrigeration unit restarts.

Technical Data of CMV Series Magnetic Check Valve:

Model	Connection Size (ODF)	Max Working Presure (bar)	Cv Value	Max. Internal Leak
CMV-4S	1/4''	55	0.7	<2.3 ml/min
CMV-6S	3/8''	55	1.2	<2.3 ml/min
CMV-8S	1/2''	48	2.7	<3.3 ml/min
CMV-10S	5/8''	48	3.3	<3.3 ml/min
CMV-12S	3/4''	48	7.2	<6.6 ml/min
CMV-14S	7/8''	48	8.0	<6.6 ml/min
CMV-18S	1 1/8''	48	13.2	<13.1 ml/min
CMV-22S	1 3/8''	48	18.9	<13.1 ml/min
CMV-26S	1 5/8''	48	27.8	<19.7 ml/min
CMV-34S	2 1/8''	48	49.9	<19.7 ml/min
CMV-42S	2 5/8''	48	61.9	<26.2 ml/min
CMV-50S	3 1/8''	45	64.1	<26.2 ml/min

Main Dimension of CMV Series Magnetic Check Valve:

Model	Connection Size		Dimension
	inch	mm	A		B		D
	inch	mm	inch	mm	inch	mm	inch	mm
CMV-4	1/4''	6	4.02	102	0.88	22	0.34	9
CMV-6	3/8''	10	4.02	102	0.88	22	0.34	9
CMV-8	1/2''	13	5.18	131	1.13	29	0.41	10
CMV-10	5/8''	16	5.18	131	1.13	29	0.53	13
CMV-12	3/4''	19	7.04	179	1.63	41	0.65	17
CMV-14	7/8''	22	7.04	179	1.63	41	0.78	20
CMV-18	1 1/8''	29	8.43	214	2.13	54	0.94	24
CMV-22	1 3/8''	35	9.41	239	2.63	67	1.00	25
CMV-26	1 5/8''	41	10.55	268	3.13	79	1.12	28
CMV-34	2 1/8''	54	12.06	306	3.63	92	1.37	35
CMV-42	2 5/8''	67	13.05	331	4.13	105	1.50	38
CMV-50S	3 1/8''	79	13.05	331	4.13	105	1.69	43

Cross Reference of Refrigeration Magnetic Check Valves:

MUELLER	Model No.	HENRY	SUPERIOR
CMV-4S	ACK-4	MS-4	900MA-4S
CMV-6S	ACK-6	MS-6	900MA-6S
CMV-8S	ACK-8	MS-8	900MA-8S
CMV-10S	ACK-10	MS-10	900MA-10S
CMV-12S	ACK-12	MS-12	900MA-12S
CMV-14S	ACK-14	MS-14	900MA-14S
CMV-18S	ACK-18	MS-18	900MA-11S
CMV-22S	ACK-22	MS-22	900MA-13S
CMV-26S	ACK-26	MS-26	900MA-15S
CMV-34S	ACK-34	MS-34	900MA-21S
CMV-42S	ACK-42	MS-42	900MA-25S
CMV-50S	/	/	/

More Refrigeration Products for you to choose:


Refrigeration Solenoid Valve	Reversing Valve	Expansion Valve

Hot Gas Bypass Valve	Crankcase Pressure Regulator	Ball Valve

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
